Autonomous Shape Sorting System (Smart Factory)

Industrial IoT & Computer Vision Sorting Conveyor System

YOLOv11ESP32ReactFastAPI
Watch DemoSource Code
1 / 6

Efficiency Gain

25% Lower GFLOPs

YOLOv11 dibanding generasi sebelumnya

Latency

< 45ms

End-to-end detection to servo trigger

Accuracy

98.4%

Reliable object geometric sorting

00 — Overview

Overview

Sistem otomasi penyortir bentuk otomatis terintegrasi yang menghubungkan deteksi objek berbasis Deep Learning (YOLOv11), backend microservice FastAPI, mikrokontroler ESP32, dan aktuator servo mekanik pada konveyor mini. Dirancang untuk mensimulasikan lingkungan smart factory dengan pemantauan analitik real-time.

01 — The Problem

The Problem

Penyortiran manual pada jalur produksi manufaktur rentan terhadap kelelahan manusia dan ketidakkonsistenan kecepatan. Proyek ini menyelesaikan tantangan tersebut dengan membangun pipeline visi komputer terkalibrasi yang berkomunikasi secara instan dengan hardware sortir fisik melalui protokol asinkron.

02 — Tech Stack

Tools & Technologies

YOLOv11 Nano
Deep LearningModel deteksi objek efisien dengan latensi inferensi ultra rendah.
FastAPI Backend
API & Vision ServerPemrosesan frame kamera dan koordinasi instruksi penyortiran.
ESP32 (C++/Arduino)
Firmware / EmbeddedLogika non-blocking state-machine pengendali motor stepper & servo.
React & Tailwind
Operator DashboardMonitoring live telemetry, statistik batch, dan pengaturan sensitivitas threshold.

03 — Key Features

Key Features

  1. 01

    Real-Time Shape & Color Classification

    Mendeteksi kubus, silinder, dan bentuk custom di atas konveyor bergerak tanpa jeda.

  2. 02

    Precision Mechanical Actuation

    Kalkulasi waktu tempuh objek menuju aktuator servo untuk eksekusi dorong tepat sasaran.

  3. 03

    Interactive Control Dashboard

    Antarmuka web untuk menyalakan/mematikan konveyor, kalibrasi threshold, dan grafik laju sortir.

  4. 04

    Non-Blocking Architecture

    Mencegah buffer overflow sinyal kendali hardware saat traffic deteksi tinggi.

04 — Gallery

Project Gallery
